Assembled Package Including Tray Defining Ridge

Patent No. 12415667

The assembled package includes an outer container including a first section and a second section, and a first tray within the outer container, the first tray defining a first ridge along a periphery of the first tray, the first ridge being held between a first peripheral edge of the first section and a second peripheral edge of the second section when the outer container is in a closed position, the first tray including first vertical sidewalls that extend downward from a first top surface of the first tray, the first ridge extending horizontally away from the first vertical sidewalls.

Inventors: Andrew T. Peeler (Richmond); Christopher L. Simpson (Richmond); Terrance T. Bache
